Yunfeng Dredger Company is one of the most reliable manufacturers and suppliers of cutter head river dredger in China. If you're going to buy the newest cutter head river dredger made in China, welcome to get quotation from our factory. All customized products are with high quality and low price.

Products Description

Anchoring booms and spud carriages can be fitted on cutter head river dredgers upon clients' request.

The dredger carries out dropping anchor /laying anchor operations with the anchoring booms powered by the hydraulic system, featuring simple and convenient operation. If no anchoring booms are installed, one work boat can be used instead. Work boat delivers greater maneuverability. After a single anchoring operation, the dredger can keep working for a long time without repeated anchoring. Apart from dropping anchor /laying anchor tasks, the work boat can also transport fuel and fresh water, shuttle crews, carry out rescue missions, and install or replace pipelines. Therefore, we tend to recommend one work boat to clients rather than spud winches.

Spud carriages are highly practical for medium and large cutter head river dredgers. With the carriage, the stern spuds can move forward rapidly, saving more operational time for dredging work. This improves sand output per unit time and raises productivity while cutting operational costs. For clients planning to purchase dredgers of model 550 and above, we strongly advise installing the spud carriage system on dredger.

Technical specifications of RYD550 cutter suction river dredger

Water flow(Slurry working capacity): 2300m3/h

Max. dredging depth: 12m

Max. discharge distance: 2000m

Main diesel engine: Cummins diesel engine or equivalent

Cutter head power: 100KW

Total power: 762KW

Fuel consumption:115L/H

The working condition of RYD450 Cuter head river dredger

The RYD450 cutter suction dredger is a medium-small dredging machine. With shallow draft and compact structure, it can work flexibly in narrow inland waterways. It is widely used for river sand mining, waterway desilting, dredging of lakes and reservoirs, as well as pond excavation and silt removal.

The vessel can be fitted with a Cummins diesel engine or equivalent, delivering stable power and long continuous working hours. The split modular hull is easy to disassemble and transport by road or barge. It features easy operation and low labour cost.

With reliable performance and competitive price, the RYD450 dredger offers outstanding cost performance and is highly favoured by clients undertaking inland dredging projects worldwide.
